GRAVITY SEPARATOR MACHINE

Get a Price/Quote

GRAVITY SEPARATOR MACHINE Specification

Features
Adjustable inclination, precise separation, high efficiency, easy cleaning

Shape
Rectangular machine with sloped deck

Tool Type
Gravity Separator

Usage & Applications
Seed cleaning, grain separation, industrial material sorting

Noise Level
Below 80 dB

Product Type
Agricultural Processing Machine

General Use
Separation of granular materials by density

Capacity
2 to 6 tons per hour (varies by model)

Weight (kg)
350 kg (approx)

Type
Gravity Separator Machine

Drive Type
Belt Drive

Power
2.2 kW - 3.7 kW (3 HP - 5 HP)

Power Source
Electric

Transmission Type
Mechanical

Engine Type
Electric motor driven

Fuel Tank Capacity
N/A (electric motor)

Engine Oil Capacity
N/A (electric motor)

Start Method
Electric Start

Machine Speed
Adjustable, typically 100-300 rpm

Production Output
Varies with material; up to 6 t/h

Material
Mild Steel/SS Contact Parts

Dimension (L*W*H)
2200 mm x 1600 mm x 1600 mm (approx)

Color
Green/Gray (customized as available)

Height Adjustment
Manual or hydraulic options available

Deck Area
1.8 m²

Voltage
3-phase, 380V/415V (customizable)

Safety Features
Overload protection, emergency stop provided

Portability
Fitted with wheels for easy movement

Cleaning System
Self-cleaning brushes for deck

Service Support
On-site installation and training available

Blower System
Integrated, adjustable airflow

Deck Type
Rectangular, perforated, adjustable inclination

Control Panel
Standard electrical control panel

About GRAVITY SEPARATOR MACHINE

GRAVITY SEPARATOR MACHINE

Make	MICROTECH
Model No.	MT-2014
Usage/Application	Canbeusedtoseparateanytypeofdrybulkpart
Deck	SINGLE
Voltage	220V
Material	MILDSTILL
AutomationGrade	Automatic

Efficient Density-Based Separation

This machine utilizes a sloped, perforated deck and integrated adjustable airflow to achieve high-efficiency separation of materials by density. Its customizable inclination allows for precise sorting of seeds, grains, and industrial materials, ensuring optimal product purity with every batch.

Flexible Operation and Easy Cleaning

Deck inclination and machine speed are both easily adjustable, accommodating a variety of material types and separation needs. The self-cleaning brush system continuously maintains deck performance, reducing downtime and enhancing productivity in demanding environments.

Designed for Safety and Portability

With built-in overload protection, emergency stop functions, and sturdy wheels, the gravity separator guarantees operational safety and convenient mobility. On-site installation, user training, and adaptable control panel options provide comprehensive support for users across diverse industrial settings.

FAQ's of GRAVITY SEPARATOR MACHINE:

Q: How does the Gravity Separator Machine separate granular materials by density?

A: The machine combines a sloped, perforated deck with an integrated blower system and adjustable airflow to stratify particles based on density. Lighter material flows upward while heavier particles settle lower, enabling effective separation in a continuous process.

Q: What types of materials can be processed using this gravity separator?

A: It can separate a wide range of granular materials, including seeds, grains, pulses, nuts, and certain industrial materials. Its versatile design makes it suitable for seed cleaning, agricultural sorting, and other density-based material processing applications.

Q: Where is the Gravity Separator Machine typically used?

A: It is commonly utilized in seed processing plants, agricultural operations, grain sorting warehouses, and industrial facilities that require precise separation of materials by density. Its mobility and robust construction suit various production environments.

Q: What are the main benefits of using the integrated blower system and adjustable deck inclination?

A: The blower system, with adjustable airflow, enhances the separation process by accurately directing material movement. Adjustable deck inclination allows users to fine-tune the sorting angle, ensuring optimal separation efficiency and improved end-product quality.

Q: How is the deck cleaned during operation, and does this affect machine performance?

A: Self-cleaning brushes continuously sweep the deck, preventing clogging and material build-up. This feature ensures consistent performance, less downtime for manual cleaning, and maintains high throughput throughout operation.

Q: What installation and user support options are available for this machine?

A: On-site installation, setup assistance, and user training are provided to ensure proper operation. Comprehensive service support helps users maximize machine efficiency and understand adjustments and maintenance routines.

Q: When should the height and speed settings be adjusted on the gravity separator?

A: Adjust height and speed whenever processing materials of different densities or sizes, or to optimize separation for specific product batches. These adjustments help maintain performance and accommodate varying operational requirements.
