SPEED CONTROL OF PMDC MOTOR USING SINGLE PHASE HALF WAVE BRIDGE CONTROLLED BRIDGE CONVERTER TRAINER

Get a Price/Quote

SPEED CONTROL OF PMDC MOTOR USING SINGLE PHASE HALF WAVE BRIDGE CONTROLLED BRIDGE CONVERTER TRAINER Specification

Type
Educational Trainer Kit

Material
Powder Coated MS Cabinet

Size
Standard Laboratory Bench Top

Input Voltage
230V 10%, 50Hz AC

Color
Blue & Grey

Dimension (L*W*H)
430mm x 350mm x 150mm (approx)

Capacity
Up to 1A Output Current

Noise Level
Low, <50dB

Display
Analog/Digital Volt & Ammeter

Output Voltage Range
012V DC (adjustable)

Motor RPM Range
15002000 rpm (typical)

Usage
Demonstration of Power Electronics and Motor Control Principles for Laboratory/Academic Purposes

Front Panel
Screen Printed with Circuit Diagram and Test Points

Firing Angle Adjustment
0180

Accessories Included
Patch Cords, Experiment Manual, Power Cord

Converter Type
Single Phase Half Wave Controlled Bridge Converter

Motor Type
PMDC (Permanent Magnet DC Motor), 12V/1A

Learning Scope
Study of Speed Control, Converter Characteristics, SCR Firing & Motor Response

Control Technique
Phase Angle Control using SCR

Protection Features
Fuse & Overload Protection

Operating Environment
050C, <70% RH

About SPEED CONTROL OF PMDC MOTOR USING SINGLE PHASE HALF WAVE BRIDGE CONTROLLED BRIDGE CONVERTER TRAINER

The SPEED CONTROL OF PMDC MOTOR USING SINGLE PHASE HALF WAVE BRIDGE CONTROLLED BRIDGE CONVERTER TRAINER is a top-rated educational kit, meticulously designed for laboratories and academic demonstrations in power electronics and motor control. This must-have value trainer features a sterling PMDC motor, monumental phase angle control with SCR, and superb overload protection. Built with a powder-coated MS cabinet, it delivers a standard bench-top experience. Its exceptional analog/digital displays and adjustable output facilitate comprehensive experiments, making it an indispensable choice for educators, distributors, and exporters across India.

Versatile Plant Application & Features

Ideal for engineering labs and plant training facilities, this SPEED CONTROL trainer enables hands-on exploration of PMDC motor speed control, SCR firing and converter characteristics. The trainer kit's superb adjustable phase angle, robust fuse and overload protection, and clearly marked test points foster deep understanding and safe usage. It's purpose-built for academic demonstration and laboratory instruction, exemplifying reliability and versatility in a controlled environment. Its must-have nature makes it a sterling addition for educational plant applications.

Seamless Delivery & Quality Assurance

Each product is professionally charged and shipped, ensuring prompt delivery within a standard timeframe-typically handed over within 10-15 business days for Indian distributors and exporters. The trainer is packaged with precision using durable, secure materials to protect all components. It is accompanied by certifications for safety and academic standards, ensuring monumental confidence in the product's quality. Value-driven service lets every customer experience a superb purchase process, emphasizing reliability from order to delivery.

FAQ's of SPEED CONTROL OF PMDC MOTOR USING SINGLE PHASE HALF WAVE BRIDGE CONTROLLED BRIDGE CONVERTER TRAINER:

Q: How does the phase angle control using SCR benefit speed variation in the PMDC motor?

A: Phase angle control via SCR enables precise regulation of the output voltage, allowing for superb speed variation and response in the PMDC motor during laboratory experiments and demonstrations.

Q: What accessories are included with the SPEED CONTROL TRAINER kit?

A: The kit comes complete with patch cords, an experiment manual, and a power cord, along with all standard components necessary for a sterling hands-on learning experience.

Q: Where is the SPEED CONTROL TRAINER typically used?

A: This trainer is mainly utilized in academic environments, such as engineering laboratories and technical training centers, for educational demonstration of motor and converter principles.

Q: What is the process for adjusting the motor speed on this trainer kit?

A: Speed adjustment is accomplished using the firing angle control knob on the front panel, which alters the SCR firing between 0-180. This process lets users observe changes in output voltage and motor speed in real time.

Q: When can customers expect the delivery of the SPEED CONTROL TRAINER after placing an order?

A: Standard delivery usually occurs within 10-15 business days from the date of order, ensuring prompt and secure handover to customers across India.

Q: How does fuse and overload protection enhance the trainer's value?

A: Fuse and overload protection provide monumental safeguarding for both the motor and converter circuits, ensuring safe operation and extending product longevity during repeated academic use.
