SCR SINGLE PHASE HALF-FULL CONTROLLED BRIDGE CONVERTER

Get a Price/Quote

SCR SINGLE PHASE HALF-FULL CONTROLLED BRIDGE CONVERTER Specification

Type
Single Phase Half/Full Controlled Bridge Converter

Material
Industrial Grade Components, Metal Chassis

Size
Standard Lab Size

Input Voltage
230V AC, 50Hz

Color
White with Blue/Black Panel Accents

Dimension (L*W*H)
470mm x 300mm x 140mm (Approx.)

Capacity
Typically up to 2A Output Current

Noise Level
Low, Silent in Operation

Connection Terminals
Banana Socket Terminals for Input & Output

No. of SCRs
4 (in Full Controlled Mode), 2 (in Half Controlled Mode)

Output Voltage Range
0 to 200V DC (Adjustable, depending on firing angle)

Display Type
Digital Volt and Ampere Meter

Application
Educational Lab Demonstrator, Power Electronics Training Equipment

Control Method
Phase Angle Firing using Variable Firing Circuit

Protection
Fuse and Overload Protection

Cooling Method
Natural Air Cooling

Included Accessories
Power Cord, User Manual, Patch Leads

About SCR SINGLE PHASE HALF-FULL CONTROLLED BRIDGE CONVERTER

Jump on the elite SCR Single Phase Half-Full Controlled Bridge Converter, an imposing and top-rated champion in power electronics training equipment. Outfitted with brilliant industrial grade components and a robust metal chassis, this lab-sized demonstrator delivers an adjustable output range of 0 to 200V DC and supports up to 2A output current. Reliable fuse and overload protection, digital voltage and ampere display, and banana socket terminals assure seamless connectivity. The converter features natural air cooling and operates silently. Proudly distributed, exported, and manufactured in India for educational excellence.

Effortless Operation and Distinctive Advantages

The SCR SINGLE PHASE HALF-FULL CONTROLLED BRIDGE CONVERTER provides clear direction of use for plant or educational applications. Featuring phase angle firing via a variable firing circuit, users can easily adjust output voltage for tailored demonstrations. Digital meters offer brilliant monitoring, while overload protection shields your setup. Included accessories, such as patch leads and a user manual, streamline operations, making this converter ideal for hands-on training in laboratories and power electronics plants.

Robust Supply, Payment Confidence, and Reliable Handover

We readily supply this champion converter across India, with rapid charge and handover processes ensuring prompt delivery. Flexible payment terms cater to diverse institutional and commercial needs. The main domestic market covers educational institutes, labs, and industrial training facilities, guaranteeing top-rated support and distribution. Dependable supply ability affirms our commitment as leading manufacturers, suppliers, and traders of high-performance equipment for elite engineering education.

FAQ's of SCR SINGLE PHASE HALF-FULL CONTROLLED BRIDGE CONVERTER:

Q: How can the output voltage of the SCR SINGLE PHASE HALF-FULL CONTROLLED BRIDGE CONVERTER be adjusted?

A: The output voltage can be adjusted from 0 to 200V DC using the variable firing angle control circuit, allowing precise tuning for different applications and experiments.

Q: What are the main protective features of this converter during operation?

A: It includes fuse and overload protection, ensuring safe operation and shielding the equipment from potential damage during practical demonstrations.

Q: Where is this converter typically used and who benefits the most from it?

A: This equipment is mainly employed in educational laboratories, power electronics plants, and industrial training facilities. It benefits students, instructors, and technical trainees seeking hands-on experience in converter principles.

Q: What process should be followed to connect the converter for use in an educational lab?

A: Simply connect the input and output through the banana socket terminals, use the provided patch leads, and consult the user manual for step-by-step guidance. Always ensure the setup adheres to safety instructions.

Q: How silent is the converter during use and what cooling method does it utilize?

A: The converter operates at a low noise level, with natural air cooling to maintain optimal temperatures and silent operation throughout practical usage.
