SINGLE PHASE AC PHASE CONTROL USING ANTIPARALLEL THYRISTOR

Get a Price/Quote

SINGLE PHASE AC PHASE CONTROL USING ANTIPARALLEL THYRISTOR Specification

Type
Single Phase AC Phase Control Using Antiparallel Thyristor

Material
FR4 PCB, Semiconductor (Silicon), Copper circuitry, Plastic casing

Size
Standard Project Kit Size

Input Voltage
230V AC, 50Hz

Color
Green PCB, Black/Transparent Casing

Dimension (L*W*H)
Approx. 18 cm x 12 cm x 5 cm

Capacity
Up to 1A AC Load Control

Noise Level
Silent Operation (electronic switching)

Mounting Type
Table top or Panel Mount on request

Isolation Type
Opto-isolator for triggering

Circuit Protection
Integrated Fuse and MOV for surge protection

Load Compatibility
Resistive and Inductive (e.g., lamps, small motors)

Safety Features
Finger safe terminals, insulated PCB layout

Operating Temperature
0°C to 50°C

Model Number
SPPC-APTY2024

Trigger Circuit
Zero crossing detector based triggering

Control Device
Antiparallel Connectivity of Two SCRs (Thyristors)

Storage Temperature
-10°C to 70°C

Indication
LED ON/OFF status indicator

Power Consumption
<2W (including control circuitry)

Phase Angle Control Method
Manual through potentiometer (variable resistor)

Test Points
Provided for waveform analysis and measurements

About SINGLE PHASE AC PHASE CONTROL USING ANTIPARALLEL THYRISTOR

Explore the dominant capabilities of our SINGLE PHASE AC PHASE CONTROL USING ANTIPARALLEL THYRISTOR (Model: SPPC-APTY2024), famed for superior manual phase angle control via antiparallel SCRs. Order today and unlock unparalleled control of resistive and inductive loads, from lamps to small motors, with finger-safe terminals and integrated fuse and MOV surge protection. Its venerable design features a robust FR4 PCB, opto-isolated triggering, zero crossing detection, and LED indication-all securely enclosed within a sleek project kit-size case. Enjoy reliable, silent, and safe operation with discount offers for bulk orders through India's leading distributor, exporter, manufacturer, supplier, and trader network.

User Directions, Advantages, and Wide Applications

For optimal use, connect your load and adjust the phase angle using the front-panel potentiometer. Its main advantage lies in precise manual control of AC power, perfect for testing and educational purposes. The system benefits resistive and inductive loads, including lighting circuits, heater control, and small motor speed regulation. The included test points allow detailed waveform study, making it ideal for labs, project demonstrations, and industrial settings where accuracy and reliability are paramount.

Packaging Details, Supply Capacity, and Export Markets

Each unit is carefully packaged using industry-standard materials to ensure product safety during transit. We offer proposal amount based on order volume, backed by efficient express shipping options for urgent requirements. The packaging is compact, protecting the product against shocks and environmental exposure. With substantial supply ability, we primarily export to Asia, Africa, and the Middle East, catering to distributors, exporters, and end-users seeking reliable power control solutions.

FAQ's of SINGLE PHASE AC PHASE CONTROL USING ANTIPARALLEL THYRISTOR:

Q: How does the antiparallel thyristor phase control device operate?

A: The device uses two SCRs connected in antiparallel, allowing manual adjustment of AC phase angle through a potentiometer. It delivers controlled power to loads by varying the firing point, providing smooth and precise control over output voltage.

Q: What are the main benefits of using this phase control kit?

A: Primary benefits include versatile compatibility with resistive and inductive loads, integrated safety protection (fuse and MOV), silent operation, and reliable manual control for educational, testing, and automation purposes. It also offers finger-safe terminals and opto-isolated triggering for enhanced safety.

Q: Where can this phase control unit be used?

A: It is ideal for laboratories, project demonstrations, industrial automation, and testing environments where controlled AC power is required for devices like lamps, heaters, and small motors.

Q: What safety measures are included in the product?

A: The product features an integrated fuse and MOV for surge protection, insulated PCB layout, finger-safe terminals, and opto-isolator-based triggering to ensure user safety and safeguard connected equipment.

Q: What are the available mounting and operating options?

A: The unit supports table-top use or can be optionally panel-mounted upon request. It operates efficiently within a temperature range of 0C to 50C, and offers simple manual control via a potentiometer.
