SPEED CONTROL OF SEPARATELY EXCITED DC MOTOR USING SINGLE PHASE HALF WAVE BRIDGE CONTROLLED BRIDGE CONVERTER TRAINER

Get a Price/Quote

SPEED CONTROL OF SEPARATELY EXCITED DC MOTOR USING SINGLE PHASE HALF WAVE BRIDGE CONTROLLED BRIDGE CONVERTER TRAINER Specification

Type
Educational Trainer Kit

Material
Mild Steel Body with Powder Coating

Size
Bench Top

Input Voltage
230V AC, 50Hz

Color
Blue and White

Dimension (L*W*H)
525mm x 375mm x 125mm

Capacity
0.5 HP Separately Excited DC Motor

Noise Level
Low

Front Panel
Printed Circuit Diagram and Connection Terminals

Meter Type
Digital Voltmeter and Ammeter

Drive Type
Armature Voltage Control

Operating Temperature
0°C to 40°C

Mounting
Table Top

Motor Type
Separately Excited DC Motor

Training Scope
Observation of speed control characteristics, converter operation, and analysis for technical education

Auxiliary Output
DC Output for Field Winding

Accessories
Connecting leads and comprehensive manual

Input Supply Frequency
50 Hz

Load
Fitted Panel with Motor and Coupling

Rectifier Type
Diode and SCR based

Speed Control Range
Wide, adjustable through firing angle

Protection
Over Current and Fuse Protection

Controller Type
Single Phase Half Wave Controlled Bridge Converter

About SPEED CONTROL OF SEPARATELY EXCITED DC MOTOR USING SINGLE PHASE HALF WAVE BRIDGE CONTROLLED BRIDGE CONVERTER TRAINER

Experience pivotal speed regulation with the New SPEED CONTROL OF SEPARATELY EXCITED DC MOTOR USING SINGLE PHASE HALF WAVE BRIDGE CONTROLLED BRIDGE CONVERTER TRAINER, now at a Reduced Price. Fitted with a paragon of technology, this trainer features a separately excited DC motor and a terrific bridge converter, offering a wide, adjustable speed control range. Enjoy digital metering, overcurrent and fuse protection, and an armature voltage control drive. Pick yours for technical education in India and benefit from its robust steel build, low noise, and user-friendly design. Supporting observation, converter analysis, and lasting performance, this kit is ideal for advanced training needs.

Versatile Training System and Exceptional Features

For directional use, connect the trainer's panel terminals as per the printed circuit diagram and observe speed characteristics via adjustable firing angle. Application areas include engineering colleges, technical training institutes, and automation labs. Special features include wide speed control range, robust protection, digital readouts, and mild steel powder-coated build. Each system includes a comprehensive manual and all essential leads, ensuring easy setup and safe operation, making it invaluable for practical learning environments.

Swift Delivery and Convenient Order Process

Once your order is completed, SPEED CONTROL OF SEPARATELY EXCITED DC MOTOR TRAINER can be delivered within the agreed timeframe, with flexible payment terms accepted. Sample units may be requested-please inquire for the asking price. Fast dispatch ensures your trainer reaches you promptly. Our team facilitates a streamlined ordering process, reliable shipment tracking, and responsive support for distributor, exporter, manufacturer, supplier, and trader requirements across India.

FAQ's of SPEED CONTROL OF SEPARATELY EXCITED DC MOTOR USING SINGLE PHASE HALF WAVE BRIDGE CONTROLLED BRIDGE CONVERTER TRAINER:

Q: How does the speed control function in this DC motor trainer kit?

A: Speed is precisely regulated using armature voltage control and adjustable firing angle, enabling students to observe and analyze different speed control characteristics for technical education.

Q: What protections are included in the SPEED CONTROL OF SEPARATELY EXCITED DC MOTOR TRAINER?

A: The trainer is equipped with both overcurrent and fuse protection, safeguarding users and ensuring device longevity during operation and experiments.

Q: When will my order for this trainer kit be delivered?

A: After order completion, the trainer kit is delivered within the specified timeframe. Fast, secure shipping methods ensure you receive your product promptly.

Q: Where can this trainer kit be used effectively?

A: This educational trainer is ideal for technical institutes, engineering colleges, research labs, and industrial training centers focused on motor control and power electronics.

Q: What process should be followed to set up and use the trainer?

A: Connect the supplied leads as shown on the printed circuit diagram, set up the motor and coupling, and use the meter to observe voltage, current, and adjust speed as required for experiments.

Q: What are the main benefits of choosing this particular trainer kit?

A: Users benefit from a wide, adjustable speed control range, digital instrumentation, robust safety, comprehensive manual, and durable powder-coated steel construction for long-term educational use.
