STUDY OF DC-DC BUCK CONVERTER

Get a Price/Quote

STUDY OF DC-DC BUCK CONVERTER Specification

Type
DC-DC BUCK CONVERTER TRAINER

Material
Powder coated MS enclosure, high grade PCB components

Size
Standard bench-top laboratory unit

Input Voltage
110V/220V AC, 50Hz

Color
Blue Grey (as per image)

Dimension (L*W*H)
280mm x 190mm x 80mm

Capacity
Up to 5A output current

Noise Level
Low, negligible for laboratory usage

Weight
Approx. 2.5 kg

Cooling
Passive air vents

Package Contents
Main trainer unit, patch cords, user manual

Testing Points
Multiple on-board test points for measurement and circuit tracing

Load Type
Resistive load module included

Control Type
Manual control (Potentiometer based)

Protection Features
Overload, short-circuit protection

Converter Topology
Buck (Step-down)

Educational Use
Suitable for technical institutes and engineering laboratories

Display
Digital voltmeter and ammeter

Working Indication
LED indication

Input Power
Mains operated, provided through IEC socket

Output Voltage Range
0V to 30V DC adjustable

Switching Frequency
Typically 20kHz-50kHz

About STUDY OF DC-DC BUCK CONVERTER

Discover Savings on this hot-selling DC-DC Buck Converter Trainer, widely recognized for its noble design and potent performance for technical institutes and engineering laboratories. This eminent model features a 0V to 30V DC adjustable output, digital display for voltmeter and ammeter, multiple test points for precise measurements, and robust overload and short-circuit protection. Designed for manual potentiometer control, it includes a resistive load module, LED working indication, and reliable passive air cooling. Shop Now to enjoy lasting durability from its powder-coated MS enclosure and premium PCB components, ideal for academic empowerment.

Competitive Edge & Extra Features

The STUDY OF DC-DC BUCK CONVERTER stands out with its eminent build and broad application media. It delivers a potent performance and competitive advantage with adjustable voltage, digital monitoring, and reliable overload safeguards. The package includes patch cords and user manual, enhancing the learning experience for students and instructors alike. This converter is perfect for practical testing, circuit tracing, and demonstration, offering all essentials for superior hands-on training in technical settings.

Certifications, Sample Policy & Packaging

We provide this trainer at the lowest price, ensuring value for every purchase order. Certifications validate its quality and capacity, while sample requests are handled with prompt charging details. Each unit is securely packaged in standard bench-top size, guaranteeing safe delivery. Our policy supports educational institutions, with user manuals and accessories included. Packaging details assure product safety, meeting all distributor, exporter, manufacturer, supplier, and trader requirements throughout India.

FAQ's of STUDY OF DC-DC BUCK CONVERTER:

Q: How is the output voltage of the DC-DC Buck Converter adjusted?

A: The output voltage is manually controlled using a high-precision potentiometer, allowing adjustment from 0V up to 30V DC for versatile laboratory applications.

Q: What protection features are included in this converter trainer?

A: The trainer incorporates both overload and short-circuit protection, ensuring safe operation during experiments and demonstrations.

Q: Where is this DC-DC Buck Converter Trainer typically used?

A: This product is designed for educational use in technical institutes and engineering laboratories, making it ideal for hands-on instruction and learning.

Q: What items are included in the package when purchasing this trainer?

A: The package contains the main trainer unit, resistive load module, patch cords, and a user manual, providing everything needed for effective setup and use.

Q: How can measurements and testing be performed accurately?

A: Multiple on-board test points and digital voltmeter/ammeter displays allow precise measurement and easy circuit tracing throughout the learning process.

Q: What benefits does the trainer's certified build and sample policy provide educational institutions?

A: Certified quality and transparent sample policy ensure reliable performance, safe delivery, and accessible purchase order processes at the lowest price for academic buyers.
