STUDY OF STAR DELTA & DIRECT ON LINE (DOL) STARTER BY PLC

Get a Price/Quote

STUDY OF STAR DELTA & DIRECT ON LINE (DOL) STARTER BY PLC Specification

Type
Star Delta & Direct On Line (DOL) Starter Study Kit by PLC

Material
Mild Steel (MS) powder coated panel with acrylic front

Size
Standard

Input Voltage
220V AC, 50Hz

Color
White and blue

Dimension (L*W*H)
600mm x 400mm x 250mm approx

Capacity
Simulates up to 3-Phase, 415V motor starting

Ambient Temperature Range
0C - 50C

Display Type
LED Indicators for process status

Usage
Laboratory/Industrial Training

Starter Type
Star Delta and Direct-On-Line (DOL) Starter

Motor Protection
Contactor & Overload Relay

Included Components
Wiring Set, Mechanical Motor, Instruction Manual

Demo Modes
Manual/AUTO Selection

Mounting Type
Table Top

PLC Brand
Siemens/Schneider/Equivalent

Learning Coverage
Star-Delta Starting, DOL Starting, PLC Interface, Troubleshooting

Wiring Method
Front Panel Banana Sockets

Control Panel Features
Integrated MCB, SMPS, Switches, Indicators

PLC Input/Output
Digital Inputs & Outputs, 8I/8O

Safety Features
Emergency Stop, Overload Protection, Short-Circuit Protection

About STUDY OF STAR DELTA & DIRECT ON LINE (DOL) STARTER BY PLC

Jump on the scarce opportunity to own the Study of Star Delta & Direct On Line (DOL) Starter by PLCa masterpiece for training and demonstration, built with eminent engineering. Featuring Siemens/Schneider/Equivalent PLCs, this remarkable kit boasts 8 digital inputs/outputs and supports star-delta and DOL motor starting. Its distinguished control panel integrates MCB, SMPS, switches, and LED indicators. Designed with reliable motor protection, exhaustive demo modes, and versatile learning coverage, this select kit is ideal for laboratory and industrial training. Safety features include emergency stop and robust protections, making it a scarce, high-value addition for trainers, distributors, exporters, and manufacturers across India.

Diverse Applications Across Industries

The STUDY OF STAR DELTA & DIRECT ON LINE (DOL) STARTER BY PLC finds broad application in laboratories, technical institutions, and industrial training centers. It can be used on any standard table or workbench, supporting hands-on learning in electrical engineering, automation, and control systems. Its commercial uses extend to distributor and supplier training programs, technical education workshops, and industrial skill developmentmaking it an invaluable resource for both academic and commercial enterprises.

Flexible Payment and Seamless Supply

Payment terms for the STUDY OF STAR DELTA & DIRECT ON LINE (DOL) STARTER BY PLC can be estimated based on order rate and volume. Typically, transactions are completed via bank transfer, and shipments are handed over at the designated FOB port in India. With the ability to supply bulk orders efficiently, distributors and exporters can rely on prompt delivery timelines. Our commitment to steady supply ensures your training needs are met consistently and seamlessly.

FAQs of STUDY OF STAR DELTA & DIRECT ON LINE (DOL) STARTER BY PLC:

Q: How does the PLC integrate with star delta and DOL starter study modules?

A: The PLC interfaces with both star delta and DOL starter circuits through dedicated digital inputs and outputs, enabling manual or automatic selection modes via front panel controls. This setup simulates real-world motor starting and protection scenarios for comprehensive learning.

Q: What safety features are included in the study kit?

A: The kit offers multiple safety features, including an emergency stop button, overload protection, and short-circuit protection, ensuring safe operation during laboratory and industrial training sessions.

Q: Where is this study kit suitable for use?

A: This kit is ideal for engineering labs, vocational training centers, technical institutes, and industrial facilities that require practical demonstration and hands-on learning in motor starting and PLC interfacing.

Q: When can users expect shipment and delivery?

A: Once payment terms are finalized and an order is confirmed at the estimated rate, units are promptly handed over to the shipping agent at a designated FOB port in India. Delivery timelines are communicated based on order quantity and location.

Q: What benefits does this kit provide to users?

A: Users gain practical experience in wiring, PLC programming, troubleshooting, and understanding star delta and DOL starting procedures. The kits integrated components and safety features further enrich the learning process, preparing trainees for real industrial scenarios.
