THREE PHASE HALF-FULL WAVE UNCONTROLLED RECTIFIER TRAINER

Get a Price/Quote

THREE PHASE HALF-FULL WAVE UNCONTROLLED RECTIFIER TRAINER Specification

Type
Three Phase Half-Full Wave Uncontrolled Rectifier Trainer

Material
Powder coated metal chassis with component mounting panel

Size
Standard laboratory trainer size

Input Voltage
415V AC, 3 Phase, 50Hz

Color
Grey

Dimension (L*W*H)
410 mm x 300 mm x 240 mm

Capacity
Suitable for demonstration of 3-phase rectification operations

Noise Level
Silent operation

Display Features
Equipped with voltmeter and ammeter for output measurements

Safety Features
Shockproof and overload protected construction

Load Arrangements
Fixed and variable resistive loads for output demonstration

Output Voltage Range
0 to 220V DC (approx., depending on load and configuration)

Test Points
Multiple test points for waveform observation and measurement

Training Application
Designed for engineering and technical education laboratories

Diodes Used
High quality power diodes for rectification

Compliance
Conforms to standard electrical laboratory safety regulations

Protection
Fuse protection for input and output circuits

Rectifier Configuration
Supports both half-wave and full-wave operation via selector switches

Mounting
Rubber feet for stable placement on laboratory surfaces

External Connections
4mm socket terminals for external load and measurement instruments

Weight
Approx. 7.5 Kg

Instructional Panel
Silk-screened circuit diagram and operating instructions

About THREE PHASE HALF-FULL WAVE UNCONTROLLED RECTIFIER TRAINER

Discover extraordinary Savings and dominant performance with the Sizzling New Three Phase Half-Full Wave Uncontrolled Rectifier Trainer. Renowned for its advanced configuration flexibility, this laboratory trainer supports half-wave and full-wave rectification via easy selector switches, offering an output voltage range up to 220V DC. Its robust, powder-coated metal chassis assures safety with shockproof, overload-protected construction and fuse protection on both input and output. Equipped with renowned high-quality power diodes, voltmeter, and ammeter, its superior test points simplify waveform measurement. The instructional panel provides clear guidance, solidifying this trainer's status as the ultimate solution for engineering education laboratories.

Material Features and Usage Type

Built with a powder coated metal chassis and component mounting panel, the trainer prioritizes durability and safety in demanding laboratory environments. Its versatile design supports both fixed and variable resistive load arrangements, accommodating a wide range of practical demonstrations. Particularly suited for engineering and technical education, it delivers practical hands-on learning for students, educators, and laboratory technicians, making it a preferred tool for comprehensive instructional use.

Supply Ability, Certifications, and Delivered Goods

The trainer is manufactured in India and supports continuous supply for both domestic and international markets. Shipped goods meet standard laboratory safety norms and are delivered with robust packaging to ensure integrity upon arrival. Certified for compliance with electrical safety regulations, it is available with flexible payment terms for distributors, exporters, suppliers, and traders. Timely shipment guarantees reliable delivery for educational institutions across all regions.
