UNIVERSAL MOTOR CONTROLLER USING ANTIPARALLEL THYRISTOR

Get a Price/Quote

UNIVERSAL MOTOR CONTROLLER USING ANTIPARALLEL THYRISTOR Specification

Type
Universal Motor Controller

Material
Industrial Grade Components and PCB

Size
Standard Panel Mount

Input Voltage
220-240V AC, 50/60 Hz

Color
Gray

Dimension (L*W*H)
180mm x 120mm x 85mm

Capacity
Up to 10 HP (typical) motor load

Noise Level
< 45 dB

Output Power Range
Up to 7.5 kW

Switching Device
SCR Thyristors, Antiparallel Configuration

Cooling Method
Natural Air Cooling (Heatsink Mounted)

Application
Speed Control, Soft Start of Universal Motors

Ambient Operating Temperature
-10°C to 50°C

Start/Stop Mechanism
Manual Switch/Push Button

Protection Features
Over Voltage, Overload, Short Circuit

Control Interface
Potentiometer/Remote Control

Control Method
Phase Angle Control using Antiparallel Thyristors

Mounting Type
Panel Mounting

Motor Compatibility
AC Universal, Single Phase Motors

Enclosure Protection
IP20

About UNIVERSAL MOTOR CONTROLLER USING ANTIPARALLEL THYRISTOR

Experience impeccable control with our Universal Motor Controller using Antiparallel Thyristors, available for instant checkout and featured in our clearance section. This lofty device offers top-rated performance, managing up to 7.5 kW output power for AC universal, single-phase motors. Crafted with lavish industrial-grade components, it ensures enhanced protection-overload, over voltage, and short circuit-while maintaining silent operation under 45 dB. Its robust IP20 enclosure and natural air cooling keep it enduring within -10C to 50C. Mount with ease and benefit from versatile control interfaces, making it a stellar choice for all distributors, exporters, and manufacturers in India.

Focused Application and Usage Guide

The Universal Motor Controller is engineered for speed control and soft start of AC universal, single phase motors. Suitable for industrial environments, it efficiently utilizes phase angle control with antiparallel thyristors for reliable motor management. To operate, simply mount the controller on standard panels and connect a potentiometer or remote interface. Direction of use involves manual switch or push-button activation, ensuring straightforward integration into control systems and industrial machinery.

Sample Policy and Supply Commitment

Our sample policy is designed to facilitate smooth evaluations for bulk buyers. Upon receiving a purchase order, sample units are shipped promptly if in stock. We maintain stock ready for fast dispatch, ensuring there is no delay in fulfilling your requirements. With an abundant supply ability, we ensure goods are shipped securely and arrive on time, optimizing procurement for distributors, exporters, and direct buyers. Reach out to confirm sample availability before order placement.

FAQ's of UNIVERSAL MOTOR CONTROLLER USING ANTIPARALLEL THYRISTOR:

Q: How do I install the Universal Motor Controller using Antiparallel Thyristors?

A: The controller can be mounted on a standard panel using the provided heatsink. Connect compatible AC universal single-phase motors and utilize either a potentiometer or a remote control interface for operation.

Q: What types of motors are compatible with this controller?

A: This unit is designed for AC universal and single-phase motors, supporting maximum output power up to 7.5 kW and accommodating up to 10 HP typical motor load.

Q: Where can I use the Universal Motor Controller for optimal performance?

A: Ideal for industrial settings and workshops, it provides speed control and soft start for machine operations, with robust protection features suitable for demanding environments.

Q: What protection features does the controller offer during operation?

A: It is equipped with over voltage, overload, and short circuit protection mechanisms, ensuring safe motor control and reliable performance even during electrical fluctuations.

Q: How can I request a sample before placing my purchase order?

A: Contact the supplier to confirm stock availability. Once your purchase order is approved, samples are shipped promptly if in stock to facilitate product evaluation before bulk purchases.
