UNIVERSAL MOTOR CONTROLLER USING ANTIPARALLEL THYRISTOR SCOPE OF LEARNING:

Get a Price/Quote

UNIVERSAL MOTOR CONTROLLER USING ANTIPARALLEL THYRISTOR SCOPE OF LEARNING: Specification

Type
Universal Motor Controller

Material
Standard Industrial Grade Components

Size
Standard Educational Module

Input Voltage
230 V AC, 50 Hz

Color
Grey/White Educational Panel

Dimension (L*W*H)
220 mm x 180 mm x 80 mm

Capacity
Suitable for single-phase universal motors up to 1 HP

Noise Level
Silent Operation

Operating Temperature
0C to 50C

Control Method
Phase Angle Control using Antiparallel Thyristors

Mounting
Table Top/Education Trainer Board

Frequency Range
47 Hz 53 Hz

Indicators
LEDs for Power and Output Status

Switching Device
Thyristor (SCR) in antiparallel configuration

Adjustment
Manual Potentiometer for Speed Variation

Protection Features
Fused Input, Overload Protection, Snubber Circuit for Transient Protection

Suitable Motors
Universal (AC/DC) motors Laboratory Scale

Accessories Included
Connecting Cords, User Manual

Compliance
Designed for Academic Curriculum and Safety Standards

Output Voltage
Variable AC Output (up to Input Supply)

Weight
Approx. 2.5 kg

Application
Educational Demonstrator, Motor Speed Control, Industrial Training Lab

About UNIVERSAL MOTOR CONTROLLER USING ANTIPARALLEL THYRISTOR SCOPE OF LEARNING:

Ending Soon: Seize this ephemeral opportunity to acquire our Universal Motor Controller using Antiparallel Thyristors-crafted for stellar performance and transcendent reliability. Designed as an educational demonstrator, this module features Phase Angle Control, variable AC output, and robust antiparallel SCR switching. With competitive pricing, it offers sensational value, accompanied by advanced protection: fused input, snubber for transient management, and overload safeguards. Ideal for labs, industrial training, and universal motor speed control, its manual potentiometer, status LEDs, and ergonomic design ensure a sensational hands-on learning experience for students and engineers alike.

Stellar Application Method and Versatile Uses

The Universal Motor Controller excels in educational settings, making it ideal for hands-on training and laboratory experiments. Its application method-including phase angle control with antiparallel thyristors-introduces users to practical motor speed regulation. This controller perfectly supports commercial uses in industrial training labs, while also serving as an effective demonstrator for academic curriculum. Beyond education, it is suitable for universal AC/DC motor speed control in test benches, maintenance workshops, and research environments.

Sensational Proposal Amount and Delivery Details

Our proposal amount includes all associated charges for the Universal Motor Controller, ensuring exceptional value for institutions and industries. Standard delivery time is prompt, leveraging leading transport services for reliable shipment. Sample units are available upon request, allowing you to assess product performance commitment-free. Export orders are managed through major Indian FOB ports, guaranteeing smooth logistics and global reach. Request your quote today and experience streamlined procurement with industry-leading customer support.

FAQ's of UNIVERSAL MOTOR CONTROLLER USING ANTIPARALLEL THYRISTOR SCOPE OF LEARNING::

Q: How does the Universal Motor Controller achieve speed control for universal motors?

A: The controller employs phase angle control using antiparallel thyristors (SCRs), allowing precise adjustment of the output AC voltage. This enables effective speed variation in connected AC/DC universal motors via a manual potentiometer.

Q: What protection mechanisms are included in the controller?

A: The unit features a fused input, overload protection, and a snubber circuit to safeguard against transient electrical disturbances, ensuring reliable and safe operation for laboratory and industrial environments.

Q: When can I expect delivery of the controller after placing an order?

A: Standard delivery time is fast, and all shipments utilize established transport services. Specific delivery times may vary based on location and order volume, but prompt fulfillment is a priority.

Q: Where is the controller most commonly utilized?

A: It is widely used in academic institutions, industrial training laboratories, and electronics research centers for demonstrating and practicing motor speed control techniques.

Q: What commercial applications benefit from this motor controller?

A: This product is valuable for laboratory-scale motor speed control, educational demonstrations, maintenance testing, and small-scale industrial automation setups, enhancing both technical training and practical applications.

Q: How do the included accessories facilitate usage?

A: The controller comes with connecting cords and a user manual, ensuring easy installation, quick setup, and straightforward operation even for users new to phase angle motor control systems.
