SPEED CONTROL OF SINGLE PHASE INDUCTION MOTOR USING MOSFET BASED PWM BRIDGE INVERTER TRAINER

Get a Price/Quote

SPEED CONTROL OF SINGLE PHASE INDUCTION MOTOR USING MOSFET BASED PWM BRIDGE INVERTER TRAINER Specification

Type
Educational Trainer Kit

Material
Powder Coated Metal Enclosure

Size
Standard Laboratory Table Top

Input Voltage
230V AC, 50Hz

Color
Blue & White

Dimension (L*W*H)
500mm x 300mm x 200mm (Approx.)

Capacity
Up to 0.5 HP Single Phase Induction Motor

Noise Level
Low

Frequency Range
Variable, typically 20Hz to 50Hz

Switching Device
High Speed MOSFETs

Protection
Overload, Short Circuit, and Overvoltage Protection

Mounting
Table-top with anti-skid rubber pads

PWM Pulse Generation
Microcontroller-based (8051 or Arduino compatible)

Ambient Temperature
0°C to 40°C (Operational)

Output Voltage
Variable AC Output for Motor Speed Control

Motor Included
Single Phase Induction Motor Included

Compliance
CE and ISO Certified Manufacturing

Application
Ideal for laboratory experiments, technical education and motor training

Accessories
Supplied with connection leads, user manual and experiment sheets

Control Technique
MOSFET-based PWM Bridge Inverter

Connectivity
BNC sockets and test points for waveform observation

Indicators
LEDs for Output On/Off, Fault & Power

Display
Digital Display for Frequency & Speed

About SPEED CONTROL OF SINGLE PHASE INDUCTION MOTOR USING MOSFET BASED PWM BRIDGE INVERTER TRAINER

Discover the latest in practical motor control with the SPEED CONTROL OF SINGLE PHASE INDUCTION MOTOR USING MOSFET BASED PWM BRIDGE INVERTER TRAINER. This highly recommended and affordable educational kit is perfect for technical institutions, offering a premier solution for hands-on motor speed control experiments. The supreme design features a microcontroller-based PWM pulse generation system (8051 or Arduino compatible) and high-speed MOSFETs for variable output (20Hz-50Hz), with digital frequency and speed display. Features include comprehensive protection, variable AC output, user-friendly indicators, CE and ISO-certified build, and a durable, powder-coated metal enclosure-making this platform perfect for academic and laboratory use across India.

Versatile Applications and Training Excellence

This premier motor control trainer is perfect for technical education, making it highly suitable for laboratory experiments, skill development sessions, and in-depth motor training projects. Designed primarily for engineering institutes, polytechnics, and vocational training centers, its robust construction and complete instructional package provide an ideal surface for hands-on studies. Educators and students alike benefit from a reliable and safe learning environment, facilitating practical knowledge acquisition and experiment repetition without compromise.

Sample Policy, Availability, and Market Reach

Sample units of this supreme induction motor trainer are available for evaluation upon request, with a transparent estimate and straightforward sample policy to streamline onboarding. Once approved, the sample can be handed over for demonstration purposes. The trainer holds strong market value both domestically and in prominent educational sectors, with India as the main domestic market. Its trusted performance and compliance keep it at the forefront for institutions looking to invest in reliable learning solutions.
